Safety Protection Solutions for Small farm and Home Yard

Get Free Sample

Electric Fence Energizer

Sweat Is Poured Into The Fields, And Fences Stand Guard Through The Night
Home / Electric Fence Energizer

How does The Electric Fence Work?

A fence energizer is like the heart of an electric fence. It gets its power from an outlet or a battery.The energizer sends quick bursts of strong electricity through the wires. If an animal touches the wire, it completes the circuit, and the electricity flows through the animal into the ground, giving it a shock.The electricity goes back to the energizer through the ground, completing the loop. This way, the fence stays charged and keeps animals away.
Electric Fence Energizer

Emits a current pulse

Conductor

Tape, wire, High Tensile which conducts the power

Posts

For fitting the conductor

Insulator

Insulate the power from the wooden or iron posts, so that it won’t flow to the ground.

Earthing

Conducts the power back to the energizer when (long) grass or touched by an animal interrupts the closed loop.

HPSFENCE Energizer New Product Recommendation

Have the indicators to show the voltage strength.
High voltage circuit protection.
Have lightning protections devices.
CE& ROHS of TUV certificate
It can be powered by battery ,adaptor and solar panel.
The newest model in 2024.
HPS200NHPS350NHPS480NHPS600NHPS800NHPS1000NHPS1200N
Input Energy2J3.5J5J6J8J10J12J
Power Source12V110V-240V / 12V110V-240V / 12V110V-240V / 15V110V-240V / 15V110V-240V / 15V110V-240V / 15V
Peak Voltage9000V9000V9000V10000V10000V10000V10000V
Average Current180mA300mA450mA450mA500mA550mA650mA
Maximum Current1.2A1.2A1.2A1.2A1.2A1.2A1.2A
Output Energy1.2J2.1J2.8J3.6J4.8J6.0J7.2J
Average Power2.2W3.6W5.4W6.75W7.5W8.25W9.75W
Maximum Distance20KM30KM45KM6OKM80KM100KM120KM

What is an Electric Fence Energizer?

It's a device that takes in electrical energy from an outside source (either a 110-240V outlet or a battery) and then pushes the energy out through the positive fence terminal in very brief, high-voltage, high-amperage pulses. The negative ground terminal absorbs any excess pulse energy back into the energizer.For horses, sheep, goats, cattle, poultry, wild animals, deer and wild boar. Low power consumption, SafeShock technology, LED lights and a ON/OFF button.

What Types of HPSFENCE Fence Energizer Have?

HPSFENCE has engineers and mold manufacturing team that have profound experience in electronic design.Since 2014, HPSFENCE has been successfully developed electronic fence energizers(AC/DC),solar fence energizer to fit the needs of our customers as well as the security, flexibility and usability demands of end users.
Battery (DC) Fence Energizers

Powered from an external battery. Must use an external battery recharger when the battery needs to be recharged. The energizer requirements will determine the type and size of battery.

Plug-in (AC) Fence Energizers
Plug-in (AC) Fence Energizers

Plugs into a standard 110-240V outlet. Should be mounted inside buildings and connected to ground rods and the fence with insulated wires. Recommended for whole-farm fence systems.

Combination (AC/DC) Fence Enerqizers

Can either be plugged directly into a 110V-240V AC outlet or connected to a 12V DC battery.

Solar Fence Energizer

A small solar panel simply collects and converts sunlight into energy that is stored in a battery.The battery supplies current to the grounded Energizer that then sends about one pulse of electric current per second down the fence.

The first step in selecting an energizer is to determine your power source. If the fence is close enough, an energizer that plugs into the hydro is often the cheapest and easiest solution. As the fence gets further away from an outlet, running wires becomes expensive and other power options start to look more attractive. Deep-cycling 12 volt marine batteries are another potential power source for an energizer. These work best when you have at least two to swap out – one battery can charge while the other powers the energizer. An energizer being powered by batteries needs to be fairly accessible, so that batteries are easy to change before they run down.For electric fences in more remote locations, a solar panel may be the best solution. These tend to be the most expensive power source for a fence, but because the panel recharges the battery, it’s less likely to lose power than batteries alone. For solar panels to be effective, they need to receive a minimum of 4-6 hours of direct sunlight every day.

Selecting an Energizer for Your Electric Fence

The size of fence charger needed is dependent upon your fencing needs. These needs are determined by four main factors:
Length of the fence
Number of wires
Power source (AC, DC or Solar)
Type of animal being contained or excluded.

HPSFENCE energizer parameter comparison chart

HPS025HPS050HPS100HPS200
Input Energy0.25J0.5J1J2J
Power Source12V12V12V12V
Peak Voltage6000V8000V9000V9000V
Average Current25mA60mA80mA180mA
Maximum Current1.2A1.2A1.2A1.2A
Output Energy0 15J0.3J0.6J1.2J
Average Power0.3W0.72W1W2.2W
Maximum Distance2.5KM5KM10KM20KM

Features of HPSFence Electronic Fence

  • Features

    Multi-Power Supply Options

    Multi-Power Supply Options

    Operates on multiple power sources, including solar panels, AC mains, or batteries, ensuring flexibility and reliability in different environments.

    Energy Efficiency：

    Incorporates advanced low-impedance technology to minimize energy loss, even in cases of vegetation contact, making it ideal for long fences.

    Durable Construction

    Durable Construction

    Designed with weather-resistant housing to withstand harsh environmental conditions such as extreme heat, rain, or cold.

    Safty

    Safety Features：

    Includes built-in protections such as overload prevention, lightning protection, and grounding fault alarms to ensure safe operation.

    Easy Installation and Maintenance：

    Comes with user-friendly installation guides and modular components for straightforward setup and minimal upkeep.

    2 Years Warranty

    2 Years Warranty：

    By a 2-year warranty, ensuring durability and dependable performance.

HPSFENCE Energizer Customization Service

Customize function

According to your functional requirements for the product, we can formulate and develop

Customize exterior

  • Exteriro design:HPSFENCE can open mold based on your brand request, customize exclusive exterior.

  • Exteriro color: According to Pantone Color, customize exclusive color of shell.

Customize packing

HPSFENCE have owns graphic designer：We offer customized services（colorful box, instruction book and sticker） based on customer request.

Customize marketing document of product

HPSFENCE offer the marketing videos, copywriting information, HD pictures and other document, its convenient for you launche and promote the product in market.

Custom Quote Get Free Samples

  • Custom Quote Get Free Samples
    • *Email
      Tel

When you buy an energizer from HPS FENCE, you purchase more than an energizer. You also obtain these benefits:

2-Year Warranty

If an energizer fails within 2 years of its date of purchase, we will replace the module or unit at our cost.

Free Replacement

FREE shipment of warranty replacement energizers.

Free Technical Support

HPSFENCE provides you with free technical support to ensure stable operation of your equipment.

NOTES: This guarantee does not cover power surges caused by lightning.

View

Product Manual

View

Product Video

Get

Free Sample

Contact

After-sales Service

Frequently Asked Questions

  • Is it ok to use my own sticker and packing for the electric fence energizer?
    Yes, it is ok. You can use your own sticker packing.
  • What about the packaging of the electric fence energizer?
    Each energizer is packed in the inner box. There is foam inside the box to protect the energizer.
  • How many joules of electric fence energizer do I need for an elephant?
    We suggest 4.8J energizer. Because elephants have thicker skin.
  • What are the power supply methods of the electric fence energizer?
    We have 3 types: DC 12V, AC 110V-240V and solar 12V.
  • What is the applicable range of the electric fence energizer?
    We have different types for you to choose. 0.5J is for 5km; 1J is for 10km; 2J is for 20km; 3.5J is for 30km; 4.8J is for 45km.
  • How do I choose an energizer?
    Please contact with us to get the suggestion. Total length of fence line–now and in the future? Species to be contained and/or deterred. Climate of site–humid, dry or both? Soil (clay, sand, rock or loam)? Conductor (steel, aluminum, electroplastic twine/tape)? Permanent, semi-permanent, temporary or mixed? Will vegetation along either side of fence be controlled by grazing and/or spraying? Power source–110v AC or battery? Existing fences or posts? Subdivision, perimeter fence or both?
